WAT53263-LI

Datasheet Download 👉🏼DATASHEET-WAT53263-LI.pdf

The WAT53263-LI is a 5MP TrueColor Fixed Turret Network Camera engineered to deliver high-quality surveillance with a 5MP resolution. It is encased in a durable metal and plastic housing that is rated IP66 for water and dust resistance, making it suitable for a variety of environments with an operating temperature range between -30°C and 60°C. The device utilizes a 1/2.8″ CMOS sensor with a 2.8mm fixed focal lens and an F1.6 aperture, providing a broad field of view of 104.9° (H) x 56.5° (V) x 119.2° (D).

Designed for effective monitoring, the camera includes smart IR capabilities with a range of up to 30m, alongside white light illumination extending to 15m for enhanced visibility. It supports intelligent behavior analysis, specifically tripwire and perimeter detection, as well as motion detection and mask alarm features. Furthermore, the camera includes a built-in microphone for audio capture and supports multiple video compression standards, such as S+265, H.265, and H.264, to optimize storage and bandwidth.

Connectivity and system integration are supported through an RJ-45 10/100 Mbps Ethernet port, with compatibility for protocols including HTTP, HTTPS, RTSP, and FTP. The camera integrates with systems supporting ONVIF Profile S/T/G, CGI, and Milestone. It is flexible in its power requirements, operating on either DC12V or PoE (802.3af).
